Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine

Suitable for small to medium-sized breweries, craft beer producers, brewpubs, and beverage manufacturing facilities, this machine provides efficient, stable, and hygienic bottle filling and capping solutions for beer, carbonated drinks, sparkling beverages, and other liquid products. It is ideal for businesses seeking a cost-effective equipment solution to expand production capacity while maintaining reliable performance and consistent product quality.

The Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine is a reliable and cost-effective solution for breweries and beverage producers seeking efficient bottle packaging operations. Designed with 4, 6, 8, or 10 filling heads, this integrated system combines bottle filling and capping functions into one compact unit, improving productivity while reducing labor and floor space requirements.

The machine is suitable for beer, carbonated drinks, sparkling beverages, and other liquid products. It typically features stainless steel construction (SUS304), sanitary piping and valves, and precise filling control to ensure consistent volume and minimal product loss.

Advantages of 4/6/8/10 Head Bottle Filling & Capping Machine

Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine built on an industrial MICET design, adapted to your real project.

Optimized for Small & Medium Beverage Producers

The semi-automatic 4/6/8/10 head bottle filling & capping machine is designed for accurate and sanitary filling of beer, carbonated drinks, sparkling beverages, and other liquid products. With multiple filling head options, it ensures stable filling speed and consistent volume control, making it ideal for small to medium-sized breweries, craft producers, and beverage production lines.

Quality Inspection and Warranty

Each Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine undergoes thorough inspection, cleaning, and testing before delivery. Key components such as filling valves, seals, and control systems are inspected to ensure reliable performance, hygienic operation, and long service life. We provide 1-year free warranty, during which all necessary replacement parts are provided free of charge.

Flexible Configuration & Upgrade Options

While maintaining the core structure of the machine, selected components such as filling nozzles, capping systems (crown cap or ROPP), CO₂ counter-pressure control, and control units can be upgraded or customized. This allows the equipment to meet different bottle sizes, beverage types, and production capacities, providing a cost-effective alternative to purchasing a brand-new bottling system.

4/6/8/10 Head Bottle Filling & Capping Machine – Parameters and Work Process

Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine is a cost-effective bottling solution designed for efficient and stable filling and capping of beer and other beverages in small to medium-sized production lines.

Technical Parameters

Parametre	Specification
Machine Type	Semi-Automatic Bottle Filling & Capping Machine
Filling Heads	4 / 6 / 8 / 10 Heads
Capping Heads	4 / 6 / 8 / 10 Heads
Filling Capacity	200–500 bottles/h (depending on bottle size)
Applicable Bottles	Glass Bottles (300–1000 ml, various sizes)
Applicable Products	Beer, carbonated drinks, sparkling beverages, other liquid products
Filling Method	Gravity or Counter-Pressure Filling (optional)
Capping Type	Crown Cap (optional ROPP)
Malzeme	Stainless Steel (SUS304)
Control System	Electrical Control Panel
Production Capacity	Depends on head configuration and bottle size
Air / CO₂ Requirement	Required for counter-pressure filling

Working Process

Bottle Loading – Empty bottles are manually placed onto the filling station.
Positioning & Sealing – Bottles are positioned and sealed to ensure accurate filling.
Filling – Liquid is filled through 4/6/8/10 heads simultaneously, ensuring consistent volume and minimal foam.
Capping – After filling, bottles are capped using the integrated capping system.
Bottle Discharge – Finished bottles are removed and ready for labeling or packaging.

4/6/8/10 Heads Bottle Filling & Capping Machine Manufacturing Process

To prepare this Semi-Automatic 4/6/8/10 Head Bottle Filling & Capping Machine for a new project, we followed a structured and quality control process.

Adım 1

Design & Planning

This 4/6/8/10 head bottling machine is designed according to customer requirements, including bottle type, size and filling capacity, to ensure efficient operation.

Adım 2

Precision Manufacturing

Key components are manufactured using high-quality stainless steel and precise machining processes to ensure durability, hygiene, and stable filling performance.

Adım 3

Assembly & Integration

All mechanical parts, filling valves, pipelines, and control systems are carefully assembled to ensure accurate and reliable operation.

Adım 4

Performance Testing

The machine is tested for filling accuracy, capping consistency, pressure control, and operational stability to ensure stable operation.

Adım 5

Quality Inspection & Shipping

After final inspection, the machine is documented and securely packed to ensure safe transportation and delivery to the customer.
